Q105 Ultrasonic Cleaner - HTM01-05 Compliant - 2L

The Q105 Ultrasonic Cleaner from Walker Electronics Limited is a HTM0105 compliant, 2 litre easy to use and reliable ultrasonic cleaner specifically designed for cleaning a wide range of instruments.

The Q105 features easy to use controls, full cycle recording including cycle length, date and time, minimum, maximum and mean cycle power and frequency. Each cycle is given a unique cycle
number and operator identification for validation and traceability.

Walker Electronics Ltd have been manufacturing and supplying ultrasonic cleaners for over 60 years and are a market leader in ultrasonic cleaning technology. All Walker Electronics Ltd Ultrasonic Cleaners are manufactured in the UK in Yorkshire by Walker Electronics Ltd and all repairs and validations are also carried out in the UK by their own skilled technicians.

Features

• Complies with HTM 01-05 and BS EN61010-1
• Validation of each cycle recording user, date, time, cycle number, frequency and power
• Interlocking lid – pauses the cycle when the lid is lifted
• Low/no fluid sensing
• Automatic 90 second degas cycle after cleaning fluid change
• Fast 3–6-minute cycles
• Temperature control to prevent coagulation of proteins factory set at 45oC
• PIC chip technology –reprogrammed on annual service
• Internal data logger for up to 100 cycles. Easily transfer logs to memory stick provided
• RS232 port for connection of a receipt printer
• Enhanced electronic control. Continually adjusts the unit’s power and frequency for unrivalled cleaning

Specifications

• Time Control: 30 seconds to 15 minutes & continuous
• Rated Voltage: 220-240 Volts AC, 50-60 Hz
• Tank Dimensions: Length 240mm x Width 130mm x Depth 100mm
• External Dimensions: Length 265mm x Width 220mm x Depth 200mm
• Working Capacity: 2.0 Litres
• Maximum Capacity: 2.5 Litres
• Net Weight (excluding accessories): 3.1kg
• Gross Boxed Weight (including accessories): 5.1kg
• Typical Generator Peak Output: 375 watts
• Typical Power Consumption: 200 watts
• Typical Ultrasonic Power Per Litre: 100 watts
• Operating Frequency: 50 kHz +/- 2 kHz
• Case Construction: EN10088 Stainless Steel
• Tank Construction: BS304 Stainless Steel
• Chassis Construction: BS1449 Aluminium
• Lid Construction: BS304 Stainless Steel
• Basket: Electropolished BS304 Stainless Steel
• Basket Dimensions: Length 200mm x Width 115mm x Depth 35mm
• Warranty: 3 Year
• Transducer Warranty: 5 Years

Contents

The Q105 unit includes:

• Basket
• Lid
• UK Mains Lead
• USB Drive
• Sample Cleaning Fluid
• Handbook
